Posted on

Check out these great 3D prints!

High resolution 3D printed mug

Keith has been working on high resolution prints lately, and has been getting great results with his LulzBot TAZ 5 and TAZ 6. The mug and tube were printed in natural ABS to minimize the effect of filament dye on print quality with .13 and .15mm layer heights.  The pictures don’t really do justice to how smooth the surfaces are. The only finishing was to remove some support material on the mug, these are as printed, not sanded or otherwise finished.  Simplify3d was used for slicing and support generation.

mug 3d print high resolution taz abs (1) mug 3d print high resolution taz abs (2) mug 3d print high resolution taz abs (3) tube 3d print taz high resolution abs (2) tube 3d print taz high resolution abs (3)

Posted on

LulzBot on Inc 500!

LulzBot manufacturer Aleph Objects #122 on the Inc 500 list of fastest growing private companies!

Listed #1 in computer hardware companies and #2 for CO companies in $14m of sales in 2015, with continued revenue growth on 2 profitable Qs in 2016

http://www.inc.com/profile/aleph-objects?cid=full500016-list-122

Posted on

LulzBot TAZ 5 Control Box Wiring

LulzBot TAZ 4 and TAZ 5 control box wiring

Where do all the connectors plug in to the RAMBo controller board in on a LulzBot TAZ 4 and TAZ 5?  Here’s a nice closeup picture to help you figure out what plugs in where.
LulzBot taz 5 control box wiring

LulzBot taz 5 control box wiringRambo1-2-conn-main

Posted on

3D Print your own Pokémon Pikachu today!

IMG_20160809_101832

Pokémon Pikachu

This 10 inch tall 3D print of a “low poly” Pokémon Pikachu  was printed for a silent auction, but I thought it would be fun to post!  For all of you Pokémon Go fans, this is for you!  It is a low poly Pikachu printed in yellow PLA on a Lulzbot TAZ 6 3D printer.  PLA  is one of the most commonly used filaments in 3D printing because it is so easy to use. PLA has minimal warping and shrinking compared to other materials, which means it thrives when making objects featuring flat surfaces and hard angles, or requiring tight tolerances for fit. The Lulzbot TAZ 6 is also available refurbished here.  You could also scale this print down and print it on a Lulzbot Mini 3D printer!

Just look at all the fun you can have with a 3D printer!  Whether you are a Pokémon fan or a hobbyist of some other kind, you can print one of a kind 3D prints to suite your needs!  From figurines to replacement parts, a 3D printer is a useful tool to have around!  We recently 3D printed something even more useful than this Pokemon, chair feet for a kitchen table.



Pokémon Pikachu

Pikachu are a species of Pokémon, fictional creatures that appear in an assortment of video games, animated television shows and movies, trading card games, and comic books licensed by The Pokémon Company, a Japanese corporation.

Pikachu Pokémon
Pikachu Pokémon
Pikachu Pokémon
Pikachu Pokémon
Posted on

LulzBot TAZ 4 and TAZ 5 metal cased 500W power supplies are in stock!

lulzbot taz 4 5 24vdv 500w power supply

LulzBot TAZ 4 and TAZ 5 metal cased 500W power supplies are in stock!

LulzBot TAZ 4 and TAZ 5 metal cased 500W power supplies are in stock!  We just got some of the first LulzBot TAZ 5 500W 24vDC power supplies for retail sale. As featured in the later production TAZ 5s, they are compatible with all LulzBot TAZ 4 and TAZ 5 printers. They feature a power switch and uprated 500W power supply for faster heating and long life.

These power supplies are manufactured by LulzBot for later production TAZ 5 3D printers, and are compatible with all LulzBot TAZ 4 and TAZ 5 3D printers. Featuring an uprated 500W 24VDC power supply and power switch so you can turn it off when not is use to extend the power supply’s life.



ADDITIONAL INFORMATION:

Weight 5 lbs
Dimensions 14 x 8 x 4 in
Condition New
Color Black



LulzBot TAZ 4 and TAZ 5 metal cased 500W power supplies are in stock!
LulzBot TAZ 4 and TAZ 5 metal cased 500W power supplies are in stock!
LulzBot TAZ 4 and TAZ 5 metal cased 500W power supplies are in stock!
LulzBot TAZ 4 and TAZ 5 metal cased 500W power supplies are in stock!
Posted on

Super cool refurbished TAZ 6 3D Printer!!

IMG_20160805_144131

Have you seen these new Lulzbot TAZ 6 3D Printers?! It is like a combination of a Lulzbot TAZ 5 and a Lulzbot Mini 3D printer!! This new printer has it all! From self leveling bed to self cleaning.  The bed is borosilicate glass covered in PEI!  Makers, educators, designers, and engineers all agree this printer is the most reliable, easy to use, and has one of the largest print volumes in it’s class!  Click and print, this is a printer that is just ready to use!  Check out our refurbished options “here”

Schools, Libraries, and Makerspaces are important partners in 3D printing! Click “Schools” for a selection of education suitable products and services, including low emissions filaments.

The Nitty Gritty Details!

Printing Specifications (all specifications subject to change without notice)

Print Area: 280mm x 280mm x 250mm (11.02in x 11.02in x 9.8in)
Print Surface: Heated Borosilicate glass bed with PEI surface
TopPrint Speed: 200mm/sec (7.9in/sec)
Average Print Speed: 30 – 50mm/sec(Using default nGen profile)
Average Volumetric Output: 300 mm3/min(Using default nGen profile)
Print Tolerance: 0.1mm (0.0039in) in X and Y axes; Z axis tolerance dependent on layer thickness
Layer Thickness: 0.050mm – 0.50mm (0.002in – 0.02 in), Dependent on nozzle size
Usable Filament Size: 3mm (0.1in)

Software:

Cura LulzBot Edition is standard. Other compatible Free Software options include OctoPrint, BotQueue, Slic3r, Printrun, MatterControl, and more Available Tool

Tool Head Upgrades

Flexystuder: Prints flexible filament materials (such as NinjaFlex®)
Dual Extruder: Prints two different rigid filament materials at once
FlexyDually: Prints rigid and flexible filament materials in a single print

Physical Dimensions

Overall Dimensions (metric): 66cm x 52cm x 52cm
Functioning Footprint: 82cm x 63cm x 52cm Packaged Dimensions: 88.3cm x 66.04cm x 29.85cm (34.75in x 26in x 11.75in)
Packaged Product Weight: 19.5 Kg. (43 Lbs.)

Electrical Power Requirements:

100-240 VAC
Power Supply: 24V
Average Power Draw: 5.3 Amps(US), 2.65 Amps(EU)

Temperature

Max operating temperature (hot end): 300°C (464°F)
Max bed temperature: 120°C (248°F)

Support

30-day money-back guarantee from IT-Works.

30-day guarantee from IT-Works.

Posted on

Print your own chair feet!

Chair foot insert replacement 3d print (1)

The Problem: Kitchen chairs!

Our kitchen chairs were what my Granny would have called, catywompus!  The plastic feet inserts broke over the years , but when we thought we would just add new ones, we discovered they were custom to the chair.   After much searching online, I found a whole lot of nothing.  I decided to save myself the hassle and hand Jamie a chair foot so that he could draw up a design in Tinkercad!  A couple of days later he handed me back a 3D printed chair foot, very similar to the one I originally gave him!

It snapped in easy peasy!   Jamie printed off enough for the rest of the chairs and ten minutes of install later our chairs were no longer ‘catywompus’.   Easiest home improvement/fix up ever!!  I am slowly discovering that having a 3D printer comes in quite handy for around the house stuff and making parts that you may otherwise have to have custom-made.   That, and it’s just a lot of fun!!

How To:
For this project Jamie used a Lulzbot Mini 3D Printer and black ABS filament.  At first we considered using a flexible filament called Ninja Flex, but decided against it.  I was concerned that with it being flexible and sort of ‘grabby’ for lack of a better description, that it would be difficult to move across the hardwood floors.  The ABS is a tough and smoother filament and moved easily on the floor, although in the end I’m not sure if that mattered because I put furniture sliders on top of the chair feet.

If you have broken things around your house or little broken parts that are difficult to come by, you may  be able to design a replacement yourself and 3D print it, just as we did these chair feet.

Chair foot insert replacement 3d print (4) Chair foot insert replacement 3d print (3) Chair foot insert replacement 3d print (1) Chair foot insert replacement 3d print (2)

Posted on

LulzBot TAZ 4 and TAZ 5 Power Suppy

taz 4 5 power supply 450 watt upgrade repair (3)

We’ve recently had demand for upgraded LulzBot TAZ replacement power supplies for customers that had the early plastic cased supplies that shipped with the LulzBot TAZ 4s and early  TAZ 5s.  The later metal cased TAZ 5 supplies are great, but replacements are in short supply.  Customers also prefer a power switch on the power supply allowing the power supply to be shut off when not is use.  This conserves power and eliminates from noise the power supply cooling fan while extend the fan’s life.

Building on the idea LulzBot used with earlier TAZs, we designed a new endcap to fit the Mean Well SE-450-24 450W 24V power supply and have assembled upgraded TAZ 4 and TAZ 5 power supplies!

LulzBot TAZ upgraded replacement power supply. With power switch.
LulzBot TAZ upgraded replacement power supply. With power switch.
Posted on

3D printed dust collection shroud for shaper

Finished assembled 3d printed shaper dust collection shroud

A woodworking shaper is a high powered wood working tool that is something like an industrial strength router table. A shaper was donated to local makerspace Loveland CreatorSpace for the woodshop that was missing dust collection covers.  Loveland CreatorSpace member Richard designed these dust collection covers, and IT-Works 3D printed them on a LulzBot Mini to last in a busy workshop with 1.5mm shell, 30% infill, and printed in strong, tough, Colorado made Inova-1800 co-polyester.

Yes, that’s glitter in the black Inova, we know a guy 😉

Finished assembled 3d printed shaper dust collection shroud
Finished assembled 3d printed shaper dust collection shroud.
Hose half of 3d printed dust collection shroud. notice the smooth finish and minimal support required
Hose half of 3d printed dust collection shroud. Notice the smooth finish and minimal support required. Look closely- the Mini and Inova made such a nice print that you can see the fine polygons in the curved surfaces!
Inside of hose section
Inside of hose section.
Shroud half mid print. notice strong 1.5mm shell and 30% infill. Color change was done with a simple filament hot swap.  Yes, that's glitter in the black filament :)
Shroud half mid print. notice strong 1.5mm shell and 30% infill. Color change was done with a simple filament hot swap. Yes, that’s glitter in the black filament 🙂
Finished shaper dust collector shroud 3d print
Finished shaper dust collector shroud 3d print.
Finished assembled 3d printed shaper dust collection shroud
Finished assembled 3d printed shaper dust collection shroud
Hose end of 3d printed shaper dust collector
Hose end of 3d printed shaper dust collector.
Underside of 3d printed dust collector
Underside of 3D printed dust collector.
